| Brand Name: | TINKO/OEM |
| Model Number: | 955565 |
| MOQ: | 1000PCS |
High Capacity 3.7V Lithium-ion Polimer Battery 502035 300mah for Electric Toys
Product Description
Lithium polymer battery, also widely known as LiPo battery, LIP battery, pr Li-polymer battery, it is a type of rechargeable lithium-ion battery that use a polymer electrolyte instead of a liquid one, and made possible by the use of high conductivity semisolid (gel) polymers.
Lithium polymer batteries has many unique advantages that makes them highly suitable and widely used for many applications. One of their most significant advantages is their shape which can be customised according to different application scene. This kind of battery is lightweight and can be made into almost any shape you want, providing flexibility for device design. This is particularly useful for consumer electronics like smartphones and laptops where space and design are key factors. Additionally, they have a lower chance of suffering from electrolyte leakage compared to their lithium-ion counterparts, as they use a polymer electrolyte instead of a liquid one. The safety profile is further enhanced due to their robustness against overcharging. Moreover, they have a low self-discharge rate, which makes them a convenient option for many electronic devices.
Product Parameters
|
NO
|
Items | Criteria | Remarks |
|
1 |
Nominal Capacity |
5000mAh |
Discharge at 0.2C after standard charge fully.
|
| 2 |
Nominal Voltage
|
3.7V | |
| 3 |
Internal Impedance
|
≤50mΩ | AC 1KHz after standard chrge |
|
4 |
Charge Voltage/ Charge Limit Voltage
|
4.2V |
|
| 5 |
Shipment Voltage
|
3.85-4.05V | |
|
6 |
Standard Charge |
0.2C CC(4.0V)/CV(4.0V) → 0.1C cutoff |
Operating Temperature 0~+10℃ |
| 0.5C CC/CV→0.02C cutoff | Operating Temperature +10~+45℃ | ||
| 0.2C CC(4.0V)/CV(4.0V)→ 0.1C cutoff | Operating Temperature +45~+55℃ | ||
| 7 |
Standard Discharge
|
0.5C CC→3.0V cutoff | Operating Temperature -20~+60℃ |
|
8 |
Fast Charge |
1.0C CC/CV→0.02C cutoff |
Operating Temperature +20~+45℃ (Fully supports 1.0C charge ) |
|
9 |
Fast Discharge |
1.0C CC→3.0V cutoff |
Operating Temperature 0~+60℃ (Fully supports 1.0C discharge ) |
| 10 |
Weight
|
About 73g | |
|
11 |
Storage Temperature |
within 1 month :-10℃~+45℃ |
Relative humidity: ≤75%RH |
|
within 3 month :-10℃~+35℃ |
|||
|
within 6 month :-10℃~+30℃ |
|
Item |
Description
|
Dimension and Spec.
|
| T | Thickness | ≤9.5 mm |
| W | Width | ≤55.3 mm |
| L | Length | ≤65.5 mm |
| A | Cell Tab Length | 9.0±2.0 mm |
| C | Cell Tab Width | 5.0±0.1 mm |
| D | Package Width | 18.0±2.0 mm |
